PHIGuard

The decision

Every schema module that stored or referenced protected health information carried a *.phi.ts filename, 18 of 48 schema modules, enforced by two review agents so that answering “which tables can hold PHI?” was a filename search instead of a code review.

Coverage of that convention went past unit tests. packages/integration’s audit-coverage suite started a real PostgreSQL instance through testcontainers rather than mocking the database, and asserted that each of 10 named PHI-adjacent mutation paths wrote its audit event, 11 event types once accepting legal documents is counted as recording the Terms and the BAA separately.

The audit trail sitting behind those tables was append-only behind a Postgres trigger, and that guarantee held against the project’s own tooling: the repository’s demo seed script counted existing audit rows before it ran and refused to delete the workspace it had created, telling the operator to recreate the database instead. Every clinic, patient record, and audit trail shown anywhere in this repository, including the screenshots above, comes from that same seed script: synthetic data generated from a fixed faker seed.

A production smoke check caught what a fully green build had missed. A deploy had removed the per-request construction of the database client and the auth instance, reasoning it was Hyperdrive boilerplate; on a multi-tenant PHI database, a Worker isolate’s shared module scope turned that into a tenant-isolation bug, and the audit trail would have gone on recording the wrong actor. turbo build, turbo typecheck and turbo test all passed regardless. pnpm smoke:prod running against the deployed Worker did not: /healthz came back 503 database:error and sign-in returned intermittent 500s, so a wrangler rollback and three restored files closed the gap the suite missed. The permanent fix kept the pattern that caused it rather than routing around it: drizzle-orm/neon-http would have removed the socket, but it also removes interactive transactions, and this codebase leans on transaction() at roughly 75 call sites, including the auditedWrite helper that writes a mutation and its audit event inside one transaction so no PHI write path exists without one. Three regression tests now fail if the scoping is removed again, which is the difference between a decision and a document.

Architecture

Two independently deployed Cloudflare Workers shared one TypeScript monorepo: a marketing plane that never touched patient data, and a product plane that did.

The marketing site’s leads and rate-limit buckets lived in Cloudflare D1, a physically separate store from the Postgres database holding PHI, which was why a browser analytics SDK was allowed on the public site and forbidden behind auth. Authenticated analytics went through a same-origin proxy with an explicit event allowlist and a scalar-only property sanitizer, so no third-party JavaScript could run on a page that could render PHI.

The health check was split in two for a similar reason on the infrastructure side. A /healthz liveness check deliberately ran no database query, because a Hyperdrive connection attempt against a suspended Neon compute wakes it and starts it billing; a separate /readyz readiness check was the only path allowed to run select 1 against the database.
